Quick Details

  • Drive Wheel: 6x4
  • Capacity (Load): 21 - 30t
  • Horsepower: 251 - 350hp
  • Condition: New
  • Transmission Type: Manual
  • Emission Standard: Euro 2
  • Fuel Type: Diesel
  • Engine Capacity: > 8L
  • Gross Vehicle Weight: 12200
  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: SINO TRUCK-SWZ
  • Model Number: ZZ3251M3441
  • Dimensions (L x W x H) (mm): 7740x2490x3250
  • color: any color you like
  • max speed: 74
  • front axle: HF7
  • rear axle: HC16
  • steering system: JL80Z
  • tyre: 12.00-20
  • driving type: 6x4

Packaging & Delivery

Packaging Details: Polish with wax before shipping to protect the truck avoid sea water erosion.
Delivery Detail: The tipper truck will be ready within 30 days

Specifications

China made SINO SWZ 6x4 18.63m3 dump truck
engine: WD615, 300hp, Euro II
transmission: 10 forward, 2 reverse
cab: one sleeper

China made SINO SWZ 6x4 18.63m3 dump truck



SPECIFICATION





Product Description







Truck Model

ZZ3251M3441

Dimension(Lx W xH)(unloaded)(mm)

7740x2490x3450

Cargo body size (L*W*H, mm)(mm)

5200*2300*1290, bottom:8mm, side:6mm

Approaching angle/Departure angle(°)

(°)

20.5/27

Overhang(front/rear) (mm

1320/1670

Wheel base (mm)

3400+1350

Max speed(km/h)(km/h)

78

Curb weight(kg)

12200

Loading Weight(kg)

35000

Engine

(Steyr technology, made in China)

Model

D 10.34 water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and intercooling, directly injection

Fuel type

Diesel

Horse Power, max(kw/rpm)

300HP

Emission

EURO II

Fuel tanker capacity L)

300

Transmission

Model

HW15710

Brake system



Service brake

Dual circuit compressed air brake

Parking brake

spring energy, compressed air operating on rear wheels



Steering system



Model

JL80Z

Front axle

HF7, Steering with double T-cross section beam

Rear axle

HC16, Pressed axle housing, central double reduction with differential locks between axles and wheels

Color

White, red,Yellow .

Tyre

12.00-20

Electrical system



Battery

2X12V/165Ah

Alternator

28V-1500kw

Starter

7.5Kw/24V

Cab

L2000 cab, (single sleeping,), all-steel forward control,55ºhydraulically tiltable to the front, 2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers







FAQ



Delivery: All the trucks and semi trailers will be finish within 20-25 working days after the deposit have been received

Payment terms: T/T and L/C

Packing: Polish with wax before shipping

Shipping: Bulk cargo vessel, RORO or container.
